This page shows the number of associations for Dot11Radio0 (802.11n, green) and Dot11Radio1 (802.11ac, blue) on subspace, a Cisco Aironet AIR-SAP3702I-A-K9 access point.
| Max 802.11n | 3.9 Associations | Average 802.11n | 3.0 Associations | Current 802.11n | 3.0 Associations | ||
| Max 802.11ac | 4.0 Associations | Average 802.11ac | 3.9 Associations | Current 802.11ac | 4.0 Associations |
| Max 802.11n | 3.3 Associations | Average 802.11n | 3.0 Associations | Current 802.11n | 3.0 Associations | ||
| Max 802.11ac | 10.0 Associations | Average 802.11ac | 4.9 Associations | Current 802.11ac | 4.0 Associations |
| Max 802.11n | 3.1 Associations | Average 802.11n | 3.0 Associations | Current 802.11n | 3.0 Associations | ||
| Max 802.11ac | 10.0 Associations | Average 802.11ac | 4.1 Associations | Current 802.11ac | 4.0 Associations |
| Max 802.11n | 4.9 Associations | Average 802.11n | 2.8 Associations | Current 802.11n | 3.0 Associations | ||
| Max 802.11ac | 10.6 Associations | Average 802.11ac | 4.2 Associations | Current 802.11ac | 3.9 Associations |
| GREEN ### | Dot11Radio0 (802.11n) Associations |
| BLUE ### | Dot11Radio1 (802.11ac) Associations |
 |
 |
 |
