UPS Voltage on starfire

This summary page shows the battery potential (hot pink) and the utility, or wall, potential (blue) of the APC Back-UPS RS 1500MS2 attached to starfire.

The statistics were last updated Thursday, 25 April, 11:20:55 EDT
`Daily' Graph (5 Minute Average)

Daily Graph

Max Battery:  27.0 V Average Battery:  27.0 V Current Battery:  27.0 V
Max Utility:  121.0 V Average Utility:  119.6 V Current Utility:  119.0 V
`Weekly' Graph (30 Minute Average)

Weekly Graph

Max Battery:  27.0 V Average Battery:  27.0 V Current Battery:  27.0 V
Max Utility:  120.7 V Average Utility:  119.5 V Current Utility:  119.0 V
`Monthly' Graph (2 Hour Average)

Monthly Graph

Max Battery:  27.0 V Average Battery:  27.0 V Current Battery:  27.0 V
Max Utility:  120.5 V Average Utility:  119.5 V Current Utility:  119.7 V
`Yearly' Graph (1 Day Average)

Yearly Graph

Max Battery:  27.0 V Average Battery:  26.5 V Current Battery:  27.0 V
Max Utility:  120.1 V Average Utility:  118.9 V Current Utility:  119.7 V
HOTPINK ###  Battery Potential in Volts
BLUE ###  Utility Potential in Volts
