UPS Voltage on scimitar

This summary page shows the battery potential (hot pink) and the utility, or wall, potential (blue) of the APC Back-UPS Pro 700 attached to scimitar.

The statistics were last updated Monday, 22 December, 21:48:37 EST
`Daily' Graph (5 Minute Average)

Daily Graph

Max Battery:  13.0 V Average Battery:  13.0 V Current Battery:  13.0 V
Max Utility:  124.0 V Average Utility:  122.1 V Current Utility:  121.0 V
`Weekly' Graph (30 Minute Average)

Weekly Graph

Max Battery:  13.0 V Average Battery:  13.0 V Current Battery:  13.0 V
Max Utility:  124.2 V Average Utility:  122.3 V Current Utility:  123.0 V
`Monthly' Graph (2 Hour Average)

Monthly Graph

Max Battery:  13.0 V Average Battery:  13.0 V Current Battery:  13.0 V
Max Utility:  124.0 V Average Utility:  122.2 V Current Utility:  123.2 V
`Yearly' Graph (1 Day Average)

Yearly Graph

Max Battery:  13.2 V Average Battery:  13.0 V Current Battery:  13.0 V
Max Utility:  123.3 V Average Utility:  122.1 V Current Utility:  122.0 V
HOTPINK ###  Battery Potential in Volts
BLUE ###  Utility Potential in Volts
