This page shows the temperatures of node 0 (orb, green) and node 1 (crystal, blue) routing engines in ra, a Juniper SRX210 chassis cluster.
| Max node 0 temperature: | 63.0 °C | Average node 0 temperature: | 62.4 °C | Current node 0 temperature: | 62.0 °C | ||
| Max node 1 temperature: | 63.0 °C | Average node 1 temperature: | 62.1 °C | Current node 1 temperature: | 62.0 °C |
| Max node 0 temperature: | 64.0 °C | Average node 0 temperature: | 62.3 °C | Current node 0 temperature: | 62.5 °C | ||
| Max node 1 temperature: | 63.0 °C | Average node 1 temperature: | 62.1 °C | Current node 1 temperature: | 62.2 °C |
| Max node 0 temperature: | 64.0 °C | Average node 0 temperature: | 62.4 °C | Current node 0 temperature: | 62.6 °C | ||
| Max node 1 temperature: | 63.4 °C | Average node 1 temperature: | 62.2 °C | Current node 1 temperature: | 62.3 °C |
| Max node 0 temperature: | 64.0 °C | Average node 0 temperature: | 61.1 °C | Current node 0 temperature: | 62.4 °C | ||
| Max node 1 temperature: | 64.0 °C | Average node 1 temperature: | 62.1 °C | Current node 1 temperature: | 62.1 °C |
| GREEN ### | Routing Engine Temperature in Celsius on node 0 |
| BLUE ### | Routing Engine Temperature in Celsius on node 1 |
 |
 |
 |
