This summary page shows the battery potential (hot pink) and the utility, or wall, potential (blue) of the APC Back-UPS Pro 1500 S attached to mercury.
| Max Battery: | 27.0 V | Average Battery: | 27.0 V | Current Battery: | 27.0 V | ||
| Max Utility: | 124.0 V | Average Utility: | 122.1 V | Current Utility: | 122.0 V |
| Max Battery: | 27.0 V | Average Battery: | 27.0 V | Current Battery: | 27.0 V | ||
| Max Utility: | 123.7 V | Average Utility: | 122.0 V | Current Utility: | 122.2 V |
| Max Battery: | 27.0 V | Average Battery: | 27.0 V | Current Battery: | 27.0 V | ||
| Max Utility: | 123.9 V | Average Utility: | 122.0 V | Current Utility: | 122.0 V |
| Max Battery: | 27.0 V | Average Battery: | 27.0 V | Current Battery: | 27.0 V | ||
| Max Utility: | 123.1 V | Average Utility: | 121.9 V | Current Utility: | 121.8 V |
| HOTPINK ### | Battery Potential in Volts |
| BLUE ### | Utility Potential in Volts |
 |
 |
 |
