This page shows the port 0 (green) and port 1 (blue) temperatures of the NVIDIA ConnectX-5 ASIC tiles in helium.
| Max Tile 0: | 57.0 °C | Average Tile 0: | 55.2 °C | Current Tile 0: | 54.0 °C | ||
| Max Tile 1: | 57.0 °C | Average Tile 1: | 55.2 °C | Current Tile 1: | 54.0 °C |
| Max Tile 0: | 57.0 °C | Average Tile 0: | 55.0 °C | Current Tile 0: | 56.3 °C | ||
| Max Tile 1: | 57.0 °C | Average Tile 1: | 55.0 °C | Current Tile 1: | 56.3 °C |
| Max Tile 0: | 57.5 °C | Average Tile 0: | 54.5 °C | Current Tile 0: | 55.7 °C | ||
| Max Tile 1: | 57.5 °C | Average Tile 1: | 54.5 °C | Current Tile 1: | 55.7 °C |
| Max Tile 0: | 91.2 °C | Average Tile 0: | 70.6 °C | Current Tile 0: | 55.2 °C | ||
| Max Tile 1: | 91.2 °C | Average Tile 1: | 70.6 °C | Current Tile 1: | 55.2 °C |
| GREEN ### | Tile 0 Temperature in Celsius |
| BLUE ### | Tile 1 Temperature in Celsius |
 |
 |
 |
