This page shows the number of associations for Dot11Radio0 (802.11n, green) and Dot11Radio1 (802.11ac, blue) on frequency, a Cisco Aironet AIR-SAP3702I-A-K9 access point.
| Max 802.11n | 4.0 Associations | Average 802.11n | 2.9 Associations | Current 802.11n | 2.1 Associations | ||
| Max 802.11ac | 18.0 Associations | Average 802.11ac | 16.0 Associations | Current 802.11ac | 16.0 Associations |
| Max 802.11n | 4.0 Associations | Average 802.11n | 1.8 Associations | Current 802.11n | 2.8 Associations | ||
| Max 802.11ac | 19.0 Associations | Average 802.11ac | 15.2 Associations | Current 802.11ac | 16.0 Associations |
| Max 802.11n | 3.9 Associations | Average 802.11n | 1.9 Associations | Current 802.11n | 2.8 Associations | ||
| Max 802.11ac | 19.0 Associations | Average 802.11ac | 15.1 Associations | Current 802.11ac | 15.0 Associations |
| Max 802.11n | 7.3 Associations | Average 802.11n | 1.9 Associations | Current 802.11n | 2.6 Associations | ||
| Max 802.11ac | 19.1 Associations | Average 802.11ac | 13.2 Associations | Current 802.11ac | 16.1 Associations |
| GREEN ### | Dot11Radio0 (802.11n) Associations |
| BLUE ### | Dot11Radio1 (802.11ac) Associations |
 |
 |
 |
