Sensors Data for atlantis

This page shows the port 0 (green) and port 1 (blue) temperatures of the NVIDIA ConnectX-5 ASIC tiles in atlantis.

The statistics were last updated Friday, 09 May, 15:01:09 EDT
`Daily' Graph (5 Minute Average)

Daily Graph

Max Tile 0:  77.0 °C Average Tile 0:  77.0 °C Current Tile 0:  77.0 °C
Max Tile 1:  77.0 °C Average Tile 1:  77.0 °C Current Tile 1:  77.0 °C
`Weekly' Graph (30 Minute Average)

Weekly Graph

Max Tile 0:  78.0 °C Average Tile 0:  77.0 °C Current Tile 0:  77.0 °C
Max Tile 1:  78.0 °C Average Tile 1:  77.0 °C Current Tile 1:  77.0 °C
`Monthly' Graph (2 Hour Average)

Monthly Graph

Max Tile 0:  77.8 °C Average Tile 0:  76.9 °C Current Tile 0:  77.0 °C
Max Tile 1:  77.8 °C Average Tile 1:  76.9 °C Current Tile 1:  77.0 °C
`Yearly' Graph (1 Day Average)

Yearly Graph

Max Tile 0:  91.2 °C Average Tile 0:  77.3 °C Current Tile 0:  77.0 °C
Max Tile 1:  91.2 °C Average Tile 1:  77.3 °C Current Tile 1:  77.0 °C
GREEN ###  Tile 0 Temperature in Celsius
BLUE ###  Tile 1 Temperature in Celsius
