UPS Load/Charge % on atlantis

This page shows the load percentage (dark red) and the battery charge (blue) of the APC Back-UPS 1500 attached to atlantis.

The statistics were last updated Friday, 13 March, 21:31:20 EDT
`Daily' Graph (5 Minute Average)

Daily Graph

Max Load  25.8 % Average Load  20.1 % Current Load  20.0 %
Max Charge  100.0 % Average Charge  100.0 % Current Charge  100.0 %
`Weekly' Graph (30 Minute Average)

Weekly Graph

Max Load  24.8 % Average Load  20.2 % Current Load  19.3 %
Max Charge  100.0 % Average Charge  100.0 % Current Charge  100.0 %
`Monthly' Graph (2 Hour Average)

Monthly Graph

Max Load  23.9 % Average Load  20.0 % Current Load  20.0 %
Max Charge  100.0 % Average Charge  100.0 % Current Charge  100.0 %
`Yearly' Graph (1 Day Average)

Yearly Graph

Max Load  24.7 % Average Load  19.7 % Current Load  20.1 %
Max Charge  100.0 % Average Charge  99.7 % Current Charge  100.0 %
DKRED ###  Load %
BLUE ###  Charge %
